PR Model

Blower uses and features

The Centrifugal blower PR model best for high-pressure values. The HEAVY DUTY structure is compatible with intensive process work in extreme conditions of pressure, temperature, dust, and corrosion. The fan wheel has a durable built with radial impeller blades characterized by self-cleaning ability. These blowers are suitable for high vacuum pressure, filtration systems and manufacturing processes that require high-pressure air supply up to 2,500 mm water pressure head.

Models: impeller diameter 650-1650 mm

Drive: belt, direct with a clutch.

Air capacity: 4000-80,000 cubic meters per hour [m^3/hr]

Static pressure: 500-2500 mm water pressure head

Building materials: carbon steel, stainless steel, anti-spark aluminum.

All the parts of the blower have been laser-cut, fully welded and built from thick metal plates, which provide mechanical strength and an EXTRA HEAVY DUTY structure. The blades fully welded to the impeller providing additional mechanical strength.

User benefits

1. EXTRA HEAVY DUTY structure and reliable building materials ensure process durability over time.

2. Significant financial savings due to the blower’s high efficiency and process durability.

3. Simple maintenance by appointed drainage.

All the facilities and systems adjusted to the customer's practical needs.
